High flow bottom mount 6 laterals -N
[BACK]
Product Details
| Serial No. | Item No. | SIZE (mm) | Diameter(inches/mm) | Slot Size | Bottom opening | ||||
| A | B | C | D | E | |||||
| JD325N | HD6260-L-N | 235 | 99 | 53 | Φ63(Φ60.3) | 216 | 13"～16" (Φ350～Φ400) | 0.2/0.3/0.4mm | 4"～8"THREAD |
| JD319N | HD6370-L-N | 350 | 161 | 53 | Φ63(Φ60.3) | 233 | 18"～20" (Φ450～Φ500) | 0.2/0.3/0.4mm | 4"～8"THREAD |
| JD320N | HD6450-L-N | 465 | 223 | 53 | Φ63(Φ60.3) | 250 | 24" (Φ600) | 0.2/0.3/0.4mm | 4"～8"THREAD |
| JD321N | HD6600-L-N | 585 | 283 | 53 | Φ63(Φ60.3) | 268 | 30" (Φ750) | 0.2/0.3/0.4mm | 4"～8"THREAD |
| JD322N | HD6700-L-N | 705 | 348 | 53 | Φ63(Φ60.3) | 285 | 36"～40" (Φ900～Φ1000mm) | 0.2/0.3/0.4mm | 4"～8"THREAD |
| JD323N | HD6900-L-N | 825 | 416 | 53 | Φ63(Φ60.3) | 303 | 48" (Φ1200) | 0.2/0.3/0.4mm | 4"～8"THREAD |
